Performance Specifications
-
Capacity wise: 1.5-Ton
-
Category wise: DC Inverter
-
Color: Golden
-
Cooling Capacity BTU: 19000
-
Running Current Cooling (A): 2.3 ~9.2
-
Power input Cooling (KW): 0.41 ~ 2.3
-
Heating Capacity BTU: 19500
-
Running Current Heating (A): 2.4 ~10.3
-
Power Input Heating (KW): 0.42 ~ 2.25
Other Parameters
-
Input Power Supply (Ph, VAC, Hz): 1PH,220V Ì´, 50Hz
-
Air Flow Volume (m3/h): 1150
-
Refrigerant Type: R-32
-
Refrigerant Amount (G): 1000
Indoor & Outdoor Parameters
-
Indoor Net Dimension (L*W*H) mm³: 1045*230*335
-
Indoor Packing Net Dimension (L*W*H) mm³): 1160*347*455
-
Indoor Net Weight (kg): 13.6
-
Indoor Gross Weight (kg): 20
-
Outdoor Net Dimension (L*W*H) mm³: 820*300*610
-
Outdoor Packing Net Dimension (L*W*H) mm³: 955*418*670
-
Outdoor Net Weight (kg): 29
-
Outdoor Gross Weight (kg): 37
Features
-
Cooling: Yes
-
Heating: Yes
-
Dry: Yes
-
Vertical Flapper Auto Swing: Yes
-
Horizontal Louvers Auto Swing: Yes
-
Air-Purification: Yes
-
WiFi: Yes
-
Self-Clean: Yes
-
Anti-Corrosion: Yes
-
Turbo Function: Yes
-
UPS Enable: Yes
Accessories
-
Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm): Copper * 2920*6*0.65 (6mm)
-
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm): Copper * 2920*12*0.65 (12mm)
-
Power Cable (Core*mm²): 3*2.5
-
Communication Cable b/w Indoor & Outdoor (Core*mm²): 4*1.5
Warranty
-
Compressor: 10 Years
-
PCB Kit: 4 Years
-
Parts: 1 Yers
