- T3 Ultra Big Ourdoor
- Upto 52°C Full BTU
- Smart Inverter
- Power Input (KW): 0.41 ~ 1.95
- Running Current (A): 2.3 ~ 8.8
- Refrigerant: R410a
- Air circulation (m³/h): 1150
Performance Specifications
-
Capacity wise: 1.5-Ton
-
Category wise:
-
DC Inverter
-
Color: Silver
-
Cooling Capacity BTU: 19000
-
Running Current Cooling (A): 2.3 ~ 8.8
-
Power input Cooling (KW): 0.41 ~ 1.95
-
Heating Capacity BTU: 19500
-
Running Current Heating (A): 2.4 ~ 10.87
-
Power Input Heating (KW): 0.42 ~ 2.25
Other Parameters
-
Input Power Supply (Ph, VAC, Hz):
- 1PH, 220V, 50Hz
-
Air Flow Volume (m3/h): 1150
-
Refrigerant Type: R-410a
-
Refrigerant Amount (G): 1450 g
Indoor & Outdoor Parameters
-
Indoor Net Dimension (L*W*H) mm³: 1015*225*325
-
Indoor Packing Net Dimension (L*W*H) mm³): 1090*415*313
-
Indoor Net Weight (kg): 14.4
-
Indoor Gross Weight (kg): 17.7
-
Outdoor Net Dimension (L*W*H) mm³: 895*342*695
-
Outdoor Packing Net Dimension (L*W*H) mm³: 1046*460*780
-
Outdoor Net Weight (kg): 42
-
Outdoor Gross Weight (kg): 48
Features
-
Cooling: Yes
-
Heating: Yes
-
Dry: Yes
-
Vertical Flapper Auto Swing: Yes
-
Horizontal Louvers Auto Swing: Yes
-
WiFi: Yes
-
Self-Clean: Yes
-
Anti-Corrosion: Yes
-
Turbo Function: Yes
-
UPS Enable: No
Accessories
-
Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm):
- Copper * 2920*6*0.65 (6mm)
-
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm):
- Copper * 2920*12*0.65 (12mm)
-
Power Cable (Core*mm²): No
-
Communication Cable b/w Indoor & Outdoor (Core*mm²): 4*1.5
Warranty
-
Compressor: 10 Years
-
PCB Kit: 4 Years
-
Parts: 1 Yers
