- Â Smart Inverter Plus
- 4 Way Airflow
- UPS Enable
- Power Input (KW): 0.41 ~ 2.20
- Running Current (A): 2.3 ~10.2
- Refrigerant: R-32
- Air Circulation (m3/h): 1100
- Capacity wise: 1.5-Ton
- Category wise: DC Inverter
- Color: Black
- Cooling Capacity BTU:: 19000
- Running Current Cooling (A): 2.3 ~10.2
- Power input Cooling (KW): 0.41 ~ 2.20
- Heating Capacity BTU: 19500
- Running Current Heating (A):”: 2.4 ~10.3
- Power Input Heating (KW): 0.42 ~ 2.25
Other Parameters
-
Input Power Supply (Ph, VAC, Hz):: 1PH,220V Ì´, 50Hz
-
Air Flow Volume (m3/h):: 1100
-
Refrigerant Type: R-32
-
Refrigerant Amount (G): 1000
Indoor & Outdoor Parameters
-
Indoor Net Dimension (L*W*H) mm³: 1015*225*325
-
Indoor Packing Net Dimension (L*W*H) mm³): 1090*415*313
-
Indoor Net Weight (kg): 14.4
-
Indoor Gross Weight (kg): 17.7
-
Outdoor Net Dimension (L*W*H) mm³: 820*300*610
-
Outdoor Packing Net Dimension (L*W*H) mm³: 955*418*670
-
Outdoor Net Weight (kg): 35
-
Outdoor Gross Weight (kg): 38
Features
-
Cooling: Yes
-
Heating: Yes
-
Dry: Yes
-
Vertical Flapper Auto Swing: Yes
-
Horizontal Louvers Auto Swing: Yes
-
WiFi: Yes
-
Self-Clean: Yes
-
Anti-Corrosion: Yes
-
Turbo Function: Yes
-
UPS Enable Yes
-
Eco Mode: Yes
Accessories
-
Installation Kit (Liquid side) Material*Length*Dia*Thickness (mm): Copper * 2920*6*0.65 (6mm)
-
Installation Kit (Gas side) Material*Length*Dia*Thickness (mm): Copper * 2920*12*0.65 (12mm)
-
Power Cable (Core*mm²): 3*2.5
-
Communication Cable b/w Indoor & Outdoor (Core*mm²): 4*2.5
Warranty
-
Compressor: 10 Years
-
PCB Kit: 4 Years
-
Parts: 1 Yers
Auto-cleaning
During the operation of an air conditioner, dirt accumulates on the evaporator, promoting bacterial growth and compromising both air quality and our health. Our patented Cold Expansion Technology tackles this issue by freezing the evaporator’s surface with ambient moisture and eliminating the dirt during the defrosting phase.
Power Backup
With an additional device, the Haier inverter Air Conditioner can operate on a UPS during a power outage. The PCB in the device smartly monitors the power supply, switching between the municipal power supply and the UPS power supply. If it detects a 0V power level, it automatically switches to UPS Power mode for low-frequency operation.
Wireless Control
With a plug-in USB design, the air conditioner can be controlled by your phone via WiFi or 3G/4G network anytime, anywhere. You can download the mobile app “Haier Smart” from the Google Play Store for Android devices and the Apple App Store for iOS devices.
